SEM206P

Programmable, suitable for Pt100 temperature probes

The SEM206P is a cost effective “smart” in head transmitter that accepts PT100 temperature sensors. It
converts sensor output over a configured range, to a standard industrial (4 to 20) mA transmission signal.
PC configuration allows the user to select range, units and burnout direction, without requiring calibration
equipment. Configuration is performed quickly using our USB port driven configurator by simply connecting two clips
to the SEM206P loop terminals and following the software instructions. Calibration set up may be saved as a file on
the PC for later use. If required, the desired range can be specified at the time of order, removing the need for user configuration.

The pt100 temperature transmitter can be ordered with any of our temperature probes and connection heads. We can supply temperature probe assemblies with the temperature transmitter included.

If you already know the specification you require, we can configure the product for you at no extra cost. Otherwise the range is not specified then the transmitter will be shipped with the default range of Pt100 0/100 deg C

FEATURE HIGHLIGHTS

SENSOR REFERENCING
The SEM206P sensor referencing via the Windows based USBSpeedlink software allows for close matching
to a known reference sensor eliminating possible sensor errors.

SENSOR BURN OUT DETECTION
If a sensor wire is broken or becomes disconnected the SEM206P output will automatically go to its user
defined level upscale or downscale and the LED illuminates.

STABILITY

The SEM206P in head transmitter incorporates the latest digital technology to ensure accurate, low drift
performance.

LED WARNING

If the SEM206P detects the sensor is out of range, then a red LED will illuminate in the transmitter to alert the user that something is wrong.
